RICS Level 2 Survey in B40

B40 centres on Birmingham Airport (BHX) and the NEC campus, making it one of the busiest commercial postcodes in the Midlands. Residential properties exist in the surrounding areas, particularly around the historic Bickenhill parish and in the residential streets serving the airport and NEC workforce. The airport has been central to the area's economy and development since the 1930s, with significant expansion in the 1950s, 1960s and again in the 1980s. Properties built during these periods have very different characteristics and survey requirements.

Bickenhill village, within B40, retains a historic character with properties dating from the 17th and 18th centuries alongside Victorian-era additions. The medieval parish church of St Peter's is a significant landmark, and the village core has the character of a Conservation Area designation - buyers should check with Solihull Metropolitan Borough Council for the exact status of any specific property. Older village properties require careful assessment of traditional construction materials, lime mortar, timber frames and the effects of centuries of settlement on structural integrity.

The post-war residential estates serving the airport workforce were built using conventional brick cavity wall construction common across the West Midlands in the 1960s and 1970s. These properties are now approaching 50-60 years old, placing them in the age band where surveys identify the highest frequency of maintenance issues. Original electrical installations, cavity wall ties from the steel-strip era, and flat-roof extensions on rear additions are recurring survey findings in this age of property across the Birmingham and Solihull areas.

B40 sits within the broader West Midlands geological context, where Mercia Mudstone - a clay-rich formation - underlies large areas of the region. Clay soils shrink in dry conditions and swell in wet periods, creating volume changes that affect building foundations over time. Properties built on shallow foundations in clay-soil areas are particularly susceptible to seasonal movement. The dry summers that have become more frequent in recent years - notably 2018, 2022 and 2023 - have accelerated clay shrinkage and associated foundation movement across the region.

Structural movement in clay-soil areas presents in characteristic ways. Diagonal cracking from the corners of window and door openings, stair-step cracking along mortar joints in brickwork, and tapered gaps at door frames are all indicators that warrant close inspection. Our surveyors record crack width, pattern, direction and position at each inspection, and interpret these against the expected seasonal movement range for the property type. Category 1 and 2 cracks (hairline to 5mm) in mortar joints on a 1960s semi are common and often non-structural. Category 3 cracks above 15mm or cracks that are displaced require specialist structural assessment before exchange.

Mature trees within 10 metres of a property's foundations are a recognised subsidence risk on clay soils. The root systems of large deciduous trees - oak, willow, poplar and plane - extract significant moisture from the soil, increasing shrinkage in summer months. Where our surveyor identifies large trees in close proximity to the structure, this is noted and your conveyancer is advised to check for any insurance claims history from the vendor or current buildings insurer.

Post-war brick properties in the B40 area share the common defect profile of their era across the West Midlands. Roof coverings on 1960s and 1970s properties are typically approaching or past their expected service life. Concrete interlocking tiles from this period are prone to surface spalling and loss of waterproofing properties, while original mortared ridge and hip cappings dry out and crack over decades of thermal cycling. Our surveyors assess ridge mortar condition by inspection from ground level and note any tiles showing surface degradation that could allow water ingress in driving rain.

Damp is a persistent issue in properties of this age. Penetrating damp through failed external pointing, rising damp where the original damp-proof course has been bridged by render or raised ground levels, and condensation in poorly ventilated bathrooms and kitchens are the three most common forms. Our surveyors take damp meter readings at regular intervals across all ground-floor external walls and note any deviation above 17% moisture content, which triggers further investigation in the report.

Outdated electrical consumer units are a common finding in B40 properties built before 1980. Original fuse boards with rewirable fuses, or early MCB boards without RCD protection, do not meet the current 18th edition wiring regulations standard. Our surveyor notes the apparent age and type of the consumer unit as a condition rating 2 item and recommends an Electrical Installation Condition Report to establish whether the full installation requires updating. Rewiring a typical 3-bedroom semi in the West Midlands costs between £2,500 and £4,500.
